PA30LPF002 - LOW PASS FILTER with integrated 30 WATT AMPLIFIER integrated
- Manufactured by: DXRADIOZONE
LOW PASS FILTER + 30 WATT Amplifier
from DXRADIOZONE.COM custom built low pass filter with integrated 30 watt amplifier
from DXRADIOZONE.COM custom built low pass filter with integrated 30 watt amplifier
10-15, 17-20, 40, 80 Meter bands
With a 1-5 watt input power and a 20-40 watt peak to peak output power.
Great for field operations or just low power operations with SDR Transceiver.
Requires a standard 11-13.8 VDC supply. Rated at 3 amps MAX at full power.
Fully copper lined case for full RF shielding.
(click on images below to see larger image)
PA30LPF002
PA30LPF002_2
PA30LPF002_2
PA30LPF002_3
PA30LPF002_4
PA30LPF002_5
PA30LPF002_6
PA30LPF002_5
